Heavy duty hanger for higher load applications
USES
High capacity Joist Hangers are suitable for timber of various heights and widths.
FEATURES
SIMPLE: Preformed to common high-capacity timber sizes including two-ply trusses.
FAST: Can be fastened with Pryda No.12-35mm Screws or 35×3.15mm Timber Connector Nails
DURABLE: 1.2mm thick Z275 galvanised G300 steel. Engineered to resist gravity loads and wind uplift loads as well as better lateral rotation*.
*JHH100 – Tongue to underside of supporting beam better resist lateral rotation. JHSS DO NOT have the tongue extension but have greater depth coverage.
INSTALLATION
For application and design capacity information, refer to the Heavy Duty Joist Hangers Data Sheet.
Pryda Heavy Duty Joist Hangers
| Product Code | Size | Pack Quantity |
|---|---|---|
| JHH100 | 140mm | 10 |
| JHSS212 | 218mm | 1 |
| JHSS275 | 281mm | 1 |
